Qidi Tech X-CF Pro Industrial Grade 3D Printer

Qidi Tech X-CF Pro Industrial Grade 3D Printer

X-CF Pro, QIDI TECH R&D team spent 13 months developing an industrial grade FFF 3d printer that can fully print carbon fiber and nylon. We redesigned the extruder system to be more suitable for printing carbon fiber materials with a mechanical motion structure and a filament dry box. The software was redeveloped after extensive testing by Qidi Tech engineers. Many thanks to the large number of Qidi Tech users who provided us with valuable experience and suggestions for our progress!

Main Features:

Design Concept: X-CF PRO is a 3d printer specially designed for printing carbon fiber and nylon filaments. Independent research and development of the latest generation single extruder system, which uses high-temperature alloy material, dual-gear extrusion, can solve the problem with the accuracy and the service life when printing carbon fiber. Another set of normal high-speed extruder can easily print PLA, ABS, PETG and other filaments.
Precision Manufacturing Process: QIDI TECH using industrial-grade manufacturing, dual z-axis and industrial guide, can achieve high precision, fast printing. Upgrading the XYZ structure, all use of industrial slides. PEI printing plate, solve printing models warp and other problems. The 3d printer’s structure is developed for the effective and accurate printing of carbon fiber. Meanwile, printing other common filaments, the speed can be increased to 120cc per hour.
New technology upgrade: A new automatic intelligent leveling mode, using Korean laser module BLTouch, taking points up to 20 points to calculate the travel prime. With the new upgraded software, it is more intelligent, especially provide more effective and accurate parameters for printing carbon fiber and nylon filaments, which can be used right out of the box. The main board is made of main core Cortex-M4 and TMC2209 driver chip, matched with 800*480mm 5 inch HD capacitive display.
Professional Filament: In order to better realize carbon fiber, high temperature nylon printing. We have developed these filaments ourselves.
QIDI TECH Service: QIDI TECH are committed to making valuable 3d printers. X-CF Pro is suitable for professional users as well as novice users. No assembly required, works out of the box. It is easy to print according to the operating instructions. We provide 12 months warranty and perfect after-sales service, any questions or problems of the machine in use can contact our Customer Service Team.
